Magnetic Shield NETIC S3-6 ET電鍍錫板、磁屏蔽合金
描述
Magnetic Shield S3-6 ET板是電鍍錫的，是一種用于電子設備磁屏蔽的成熟合金。電鍍錫提高了導電性，從而增強了EMI屏蔽、卓越的耐腐蝕性以及接地連接、電路板安裝和原型構造的良好可焊性。由于錫涂層，不建議在制造后退火。
磁屏蔽合金用于需要磁屏蔽衰減的地方，但不要求磁AA合金具有極高的磁導率。
NETIC ET屏蔽合金以0.015英寸/0.38毫米厚的薄板形式出售，或以0.010英寸/0.254毫米厚.
剪切或下料服務:根據您的要求，可以將原料板剪切成更小的坯料。
產品規格
| Item Number | Thickness | Width | Length |
| NET015-36-15 | 0.015 in 0.381 mm | 36.00 in 914.4 mm | 15.00 in 381.0 mm |
| NET015-36-30 | 0.015 in 0.381 mm | 36.00 in 914.4 mm | 30.00 in 762.0 mm |
| NET015-36-60 | 0.015 in 0.381 mm | 36.00 in 914.4 mm | 60.00 in 1524.0 mm |
| NET015-36-120 | 0.015 in 0.381 mm | 36.00 in 914.4 mm | 120.00 in 3048.0 mm |
AVAILABLE PRODUCT TYPES:
Product Available Thickness Available Sizes (inches) Anneal
type inches [mm] width length type
NETIC? Foil .004 [0,10] up to 15″ sold per foot Stress
NETIC? S3-6 .014 to .095 [0,36] to [2,41] up to 30″ up to 120″ Stress
NETIC? ET .010 to .015 [0,25] to [0,37] up to 36″ up to 120″ Stress
