高功率偏振不敏感光環行器
特性
低插入損耗和PDL
高隔離和高回波損耗
無環氧光路
應用程序
EDFA, DWDM和OTDR
DWDM和OADM網絡
雙向傳輸系統
產品規格
| Parameter | Unit | Specifications | |
|---|---|---|---|
| Grade | P | A | |
| Operating Wavelength | nm | 1550±30 | |
| Insertion Loss | dB | ≤0.901) ≤1.12) | ≤1.21) ≤1.42) |
| Minimum Isolation | dB | ≥401) ≥352) | |
| Polarization Dependent Loss | dB | ≤ 0.15 | |
| Return Loss | dB | ≥ 50 | |
| Channel Crosstalk | dB | ≥ 50 | |
| Optical Power | W | ≤ 1, 2, 3, or 5 | |
| Polarization Mode Dispersion | ps | ≤ 0.10 | |
| Operating Temperature | °C | – 0 to +70 | |
| Storage Temperature | °C | – 40 to +85 | |
| Package Dimensions | mm | A=?5.5 x L63 M=?5.5 x L50 | |
Note:
1) Measured at center wavelength under 23°C for all SOP.
2) Measured at center wavelength under 0~70°C for all SOP.
All values referenced are without connector.
