自由空間隔離器
特性
高的隔離
偏振依賴
無環(huán)氧光路
緊湊的尺寸
多功能包
應用程序
光發(fā)送機
激光二極管封裝
訂購參考信息
產(chǎn)品規(guī)格
| Parameter | Unit | Specifications | |||
|---|---|---|---|---|---|
| Operating Wavelength | nm | 1310, 1550 and others | |||
| Stage | Single | Dual | |||
| Grade | P | A | P | A | |
| Typical Peak Isolation | dB | 42 | 40 | 60 | 55 |
| Insertion Loss (lc, 23°C ) | dB | ≤ 0.20 | ≤ 0.25 | ≤ 0.30 | ≤ 0.35 |
| Clear Aperture | mm | ≥ 0.90 | ≥ 0.80 | ||
| Tilt Angle of Input Light | ° | 5 | |||
| Optical Power | mW | ≤ 500 | |||
| Operating Temperature | °C | – 5 to +70 | |||
| Storage Temperature | °C | – 40 to +85 | |||
| Package Dimensions | See “Ordering Information” | ||||
