VA210-0.9-1.7-L AOTF成像系統
Brimrose Corporation of Americahas introduced a new series of?Acousto-Optic Tunable Filter (AOTF) Camera Video Adapters. This Adapter is designed for NIR spectra imaging and has a Nikon 70-300mmSRL objective lens in front of the AOTF.? The AOTF imaging system with Brimrose Synthesizer Electronics provides narrow bandwidth, rapid wavelength selection, and intensity control.? The designed wavelength ranges depend on the camera lens and Brimrose’s AOTF devices.? The high spatial resolution of the AOTF Camera system will be?up to 1280 X 960 pixels.
| Specifications | VA210-0.9-1.7-L |
| Device Type | Image Quality AOTF (aperture size 10 x 10 mm) |
| Wavelength range | 900-1700nm* |
| Spectral Resolution | 5 – 20 nm |
| Spatial Resolution | >100 line pairs/ mm |
| Working Distance | Depends on Camera Lens |
| Field of View | 16 deg with Brimrose SWIR Lens (f22.5/F3.5) |
| Working Aperture | F5.6-F22 |
| Connection with Camera | C-Mount** |
| Connection with Front Objective Lens | C-Mount with a F-Mount adapter |
| CCD Camera | 1/2” or 2/3” ** (Camera Provided by customer) |
| Driving Power | ~2 Watts |
| RF Connector | SMA |
| Drive Frequency | 120 –??60 MHz |
| Weight | 1 kg |
| Dimension | 60 x 70 x 177 mm |
SPF?
| Model | VFI-90-60-SPF-B2-C2-X-Y-Z |
| Frequency Range | 60-120 MHz |
| Frequency Step Size (Hz) | 10 Hz |
| Frequency Accuracy (%, 15 – 75°C) | 0.0001 |
| Frequency Switching Speed (ns) | 8 ns |
| Minimum Duration of Each Step (ns) | 32 ns for sweeping mode1?ms for hopping mode |
| Phase Noise | < -45 dBc/Hz @ 1 KHz in 1 Hz bandwidth |
| Output Power | 2.0 W * max. |
| External Modulation | TTL compatible, 0-5V, 330 ohms input impedance |
| Power Control | 12 bit attenuator with 25 dB range (minimum) |
| Output Impedance (W) | 50 |
| Output Connector | SMA |
| Option X | Synchronization Output |
| Option Y | Trigger Input (TTL level) |
| Option Z | Software Development Kit (SDK) as DLL |
