加拿大Current Scientific Corporation NN 3040船用熱成像相機

加拿大Current Scientific Corporation NN 3040船用熱成像相機

Current Scientific Corporation Night Navigator™3040在陀螺穩定傳感器平臺中集成了HD LWIR非制冷熱成像儀、高清（HD）日間攝像頭/低光。

Current Scientific Corporation NN 3040規格：

Thermal Camera
Sensor TypeHD Uncooled Long Wave Infrared (LWIR), 8-14μm
Resolution1024×768 pixels, 30fps
Field of View68.4° to 9.9°
Optical Zoom7x
Detection RangeNATO Target >6.7km
Day Camera
Resolution1920×1080 pixels, 30fps
Field of View63.7° to 2.3°
Optical Zoom30x continuous zoom
Low Light Camera0.0015 lux
Payload Specifications
StabilizationGyro and video stabilization
Pan RangeContinuous 360° AZ rotation
Tilt Range+/-90° elevation movement, including stow position
Weight≤25 kg [55lbs]
Dimensions427mm H x 273mm W [17in H x 11in W]
System Interface
Video StreamingRTSP H.264 with Picture-in-Picture or 2 simultaneous video streams
ControlOver IP network
Radar / AISARPA target, radar cursor, AIS target tracking over NMEA 0183 via RS422 or RS232 or Network
Features
EnvironmentalIP67
Operational Temperature-20°C to +50°C
Video TrackingOptional
Control OptionsVideo integrated into UI / Control only UI / Compact Controller / Rugged Rigid Grip / 2-Button Joystick
Third Party InterfaceProtocol for integration into navigation system / video management system / C2
Video RecordingNetwork recording of two video streams on VMS or dedicated DVR
Power Requirements
Voltage24 to 36VDC
Max. Consumption320W
