S3-E100D40是一款高性能振動與沖擊記錄儀，集成了壓電式加速度計、輔助電容式加速度計及其他環境傳感器。憑借其廣泛的適用性，該型號已成為通用測試領域最受歡迎的解決方案。
應用領域
為您的特定應用輕松建立可靠的沖擊、振動及環境測試方案！
深入探索我們的應用頁面，獲取專業領域資源。
核心應用：
? 振動傳感與記錄
? 沖擊碰撞測試
? 運輸過程監測
? Wi-Fi無線監控
? 環境試驗驗證
產品特性
便捷高效
? 一體化測量系統：集成傳感器、存儲模塊及可充電電池
? 符合人體工學的手持式設計
? 通過USB接口快速配置，五分鐘即可完成部署
靈活適配
? 多量程加速度計組合，實現寬動態范圍測量
? 單系統集成多種嵌入式傳感器
? 支持用戶自定義喚醒條件及采樣頻率
軍工可靠
? 歷經2000余家客戶及美國海軍嚴苛環境驗證
? 采用NIST可溯源加速度計校準體系 | 核心優勢 | 提供校準證書
? 億級數據點存儲容量，滿足長時間監測需求
| Accelerometer Type | Range | Sampling Rate | Bandwidth | Noise | Resolution |
| Piezoelectric | ± 100g | 20,000 Hz | 5 to 1,000 Hz | < 0.04 gRMS | 0.003 g |
| Digital Capacitive | ± 40g | 4,000 Hz | 0 to 300 Hz | < 0.01 gRMS | 0.00008 g |
| Sensor | Measurement Range | Resolution | Sampling Rate |
| Gyroscope | 2000°/s | 0.06 °/s | 0 (o?) to 3,200 Hz |
| Magnetometer | ± 1300 μT | 0.3 μT | 0 (o?) to 10 Hz |
| Temperature | -40 to 85 °C | 0.01 °C | 0 (o?) to 10 Hz |
| Pressure | 1 to 200 kPa | 1.6 Pa | 0 (o?) to 10 Hz |
| Humidity | 0 to 100 %RH | 0.04% RH | 0 (o?) to 10 Hz |
| Light | 0 to > 20 uV | <100 mlx | 0 (o?) to 4 Hz |
| Parameter | Range | Notes |
| Operating Temperature | -10°C to 80°C (14°F to 176°F) | |
| Recommended Storage Temperature | 15°C to 30°C (59°F to 86°F) | Recharging Temperature 0°C to 45°C (32°F to 113°F) |
| Humidity | 0 to 95 %RH | Non-Condensing |
| Pressure | 20 kPa to 110 kPa (2.9 psi to 16.0 psi) | Absolute Pressure |
| Shock Limit | >3,000 g | |
| No Electric Field Susceptibility | 2 MHz to 18 GHz @ 200 V/m | |
| No Magnetic Field Susceptibility | 30 Hz to 100 kHz |
| Sample Rate | Storage Capacity | Continuous Recording | Main Accel. Trigger | 2nd Accel. Trigger | Periodic/Time Trigger |
| 100 Hz | 22 days | 13 hours | 13 hours | 52 hours | 52 days |
| 1,000 Hz | 9 days | 12 hours | 13 hours | 52 hours | 49 days |
| 5,000 Hz | 63 hours | 9 hours | 13 hours | 52 hours | 38 days |
| 20,000 Hz | 17 hours | 5 hours | 13 hours | 49 hours | 20 days |
