GOVISC?SPECIFICATION
|
|
|
|
PERFORMANCE
|
Range |
0 – 100,000cP over 5 models |
|
Measurement Time |
1 second |
|
Accuracy |
1% of reading or +/- 1 digit |
|
Repeatability |
0.3% of reading or +/- 1 digit |
OUTPUTS
|
Analog |
4-20mA configurable, representing viscosity, ref. viscosity, or temperature |
|
Digital |
RS485 ModBus Data Link to host system or PC running ViscoLink |
|
USB |
USB II Plug and Play through VP100 Interface |
TEMPERATURE
|
Integral Thermometer |
Integrated tip mounted temperature measurement |
|
Standard Range |
-20 °C to 150 °C |
|
Extended Range |
To order for greater than 150 °C * |
SENSOR PROJECTION
|
Nominal sensor projection |
300mm |
ELECTRICAL CONNECTION
|
Cable Length |
As required – not affected by cable length. |
|
Cable/Connector Type |
Tyco M9 |
|
Power |
USB powered through VP100 Interface |
CONSTRUCTION
|
All welded, crevice-free |
MATERIALS
|
Sensor |
SS316 ( EN 1.4401) |
|
Sensor Options: |
Alloy C22 (EN 2.4602) |
|
|
Alloy C276 (EN 2.4819) |
|
Special Materials: |
Non-standard materials to order * |
SURFACE FINISH
|
Standard |
N5 0.4 Ra |
|
Finish Options |
Fluoropolymer |
|
|
Electropolished |
|
|
Electroplated |
|
Special Finish |
Non-standard finish options and coatings to order * |
WEIGHT
|
|
700g |
INGRESS PROTECTION
|
Standard |
IP65 |
SOFTWARE
|
ViscoLink data viewing and logging PC software |
|
|
|
* SPECIAL OPERATIONS
|
Custom variations to instrument specification and dimensions routinely provided by our dedicated Special Operations division |
|
|
|
| As it is Hydramotion’s policy to continuously develop and improve its products, some specifications may change without notice |
