RWP-024-4XR是用于銑削應用的0.75英寸燕尾夾具系統。本產品是為模塊化應用設計的:利用四個RWP-024夾具在線加工較長的零件。

這種夾具的多功能性使您既可以容納4個重8磅/尺寸(L x W x H) 2.0″ x 2.0″ x 2.0″的工件，也可以容納一個重32磅/尺寸(L x W x H) 16.5″ x 4.0″ x 4.0″的長工件。

夾具由17-4不銹鋼制成

?產品參數:



For FixtureRWP-024, RWP-024SS
Connects toAny Machine



Dovetail Width0.750in
Dovetail Height.125in
Max Workpiece Weight32 ?Pounds
Max Workpiece Width4.00 In
Max Workpiece Length16.60 In
Max Workpiece Height4.00 In
Fixture MaterialAluminum
Number of Clamps4 Clamps
Clamp Part NumberRWP-CL302SQ
