Taylor的經濟型風冷渦流底盤Dynos可以節省成本，因為它們不需要水循環系統，是中型或重型單軸或雙軸卡車和公共汽車的快速功率檢查和其他短期測試的絕佳選擇。適用于單軸或雙軸車輛的托架式或單輥（頂部安裝）測功機，車輛連續功率范圍為50馬力至622馬力（37千瓦至464千瓦），Taylor的底盤測功機在滿載時允許90英里/小時（145公里/小時）的最高推薦速度。我們的專家不僅可以幫助您選擇最佳系統，還可以為與您的操作無縫集成的整體解決方案提供設計、配置、安裝和培訓。

CM-51-EC Eddy Current Chassis Dynamometer

Specifications
Weight Capacity: 25,000 lb (11,340 kg) per axle
Roll Brakes: pneumatically-actuated disc
Shipping Weight: 8,340 lb (3,783 kg)
Capacity: 622 hp at 45 mph (464 kW at 72 kph)
Rolls: 20 by 36 in. (508 by 915 mm) long
4 front fixed rolls, 2 rear rolls fixed to
accommodate axle spreads from
48 to 60 in. (1,219 to 1,524 mm)
tandem centers
Pit Required Depth: 25 in. (635 mm)

CM-51S-EC Eddy Current Chassis Dynamometer

Specifications
Weight Capacity: 25,000 lb (11,340 kg) per axle
Roll Brakes: pneumatically-actuated disc
Shipping Weight: 5,100 lb (2,312 kg)
Capacity: 311 hp at 45 mph (232 kW at 72 kph)
Rolls: 20 by 36 in. (508 by 915 mm) long, 4 fixed
Pit Required Depth: 25 in. (635 mm)

CM-51SR-EC Eddy Current Chassis Dynamometer

Specifications
Weight Capacity: 25,000 lb (11,340 kg) per axle
Roll Brakes: pneumatically-actuated disc
Shipping Weight: 5,100 lb (2,312 kg)
Capacity: 311 hp at 45 mph (232 kW at 72 kph)
Rolls: 20 by 36 in. (508 by 915 mm) long, 2 fixed
Pit Required Depth: 25 in. (635 mm)
